6.5 Inch Lift Kit - X-Series - Jeep Cherokee XJ 2WD/4WD (1984-2001)
allowing for a super smooth highway ride and outstanding control in rugged off-road situations - all from the same shock. So if you're looking for longevity and an uncompromising ride, look no further. Rough Country's X-Series N3 features the best of the best in off-road hardware.
  • Easy bolt-on installation
  • Flex joints feature a massive 2.5" diameter body and 1.25" thread
  • Fully greaseable
  • Upper joints pivot up to 20 degrees
  • Lower joints pivot up to 35 degrees.
  • Increased ground clearance
  • Levels the front with the rear of the vehicle
  • Quick disconnects quickly and easily store out of the way when not in use
  • Front adjustable track bar is made of forged solid steel for unsurpassed strength and durability
  • Includes application valved N3 series shock absorbers which offer the best in balanced performance for on and off-road use
  • X-Flex control arm features: Clevite brand OEM style rubber bushings

Information:

Does NOT fit models with AX5 transmission. A Slip Yoke Eliminator with CV Driveshaft are highly recommended to avoid driveline vibration. If running 35" tires, they will require fender trimming to clear.

Application Summary:

Year Make/Model
1984-2001 Jeep Cherokee
Attributes
California Proposition 65 WARNING: Cancer - www.P65Warnings.ca.gov
Category Susp Lift Kits 4wd
Country of Origin (Primary) US
Front Components Lifted coil springs Adjustable upper control arms Adjustable lower control arms Transfer case drop kit Forged adjustable track bar Track bar bracket Power steering pitman arm Sway-bar quick disconnects Brake line brackets Hardware, Lifted coil springs Adjustable upper control arms Adjustable lower control arms Transfer case drop kit Forged adjustable track bar Track bar bracket Power steering pitman arm Sway-bar quick disconnects Brake line brackets Hardware
Front Kit Componenets Lifted coil springs, Adjustable upper control arms, Adjustable lower control arms, Transfer case drop kit, Forged adjustable track bar, Track bar bracket, Power steering pitman arm, Sway-bar quick disconnects, Brake line brackets, Hardware
Front Kit Components Lifted coil springs, Adjustable upper control arms, Adjustable lower control arms, Transfer case drop kit, Forged adjustable track bar, Track bar bracket, Power steering pitman arm, Sway-bar quick disconnects, Brake line brackets, Hardware
GTIN 00843030124694
Harmonized Tariff Code (Schedule B) 8708809900
Hazardous Material Code N
Install Time 6-8 hours, 6-8 hours
Life Cycle Status Code Available to Order
Lift/Drop Height 6.5 in.
NAFTA Preference Criterion Code B
Rear Components Lifted leaf springs Adjustable lift shackles Brake line brackets U-bolts Hardware, Lifted leaf springs Adjustable lift shackles Brake line brackets U-bolts Hardware
Rear Kit Components Lifted leaf springs, Adjustable lift Shackles, Brake line brackets, U-Bolts, Hardware
SDR Required Flag N
Shipping Options No Restrictions
Ships in Multiple Boxes Y
Tire Info 33x12.50R15:15x8:5x4.5:-19:-;33x10.50R15:15x8:5x4.5:-19:-;33x12.50R15:15x8:5x4.5:-18:-;33x10.50R15:15x8:5x4.5:-18:-;33x10.50R15:15x8:5x4.5:+0:-;33x10.50R15:15x8:5x4.5:+1:-;33x12.50R15:15x10:5x4.5:-39:Trimming Required;33x12.50R16:16x8:5x4.5:-6:-;285/75R16:16x8:5x4.5:-6:-;285/75R16:16x8:5x4.5:+0:-;285/75R16:16x8:5x4.5:+1:-;285/75R17:17x8:5x4.5:-19:-;285/75R17:17x8:5x4.5:-18:-;275/70R17:17x8.5:5x4.5:-12:-;33x12.50R17:17x8.5:5x4.5:+0:-;285/70R17:17x8.5:5x4.5:+0:-;33x12.50R17:17x8.5:5x4.5:+1:-;285/70R17:17x8.5:5x4.5:+1:-;33x12.50R17:17x9:5x4.5:-12:-;285/70R17:17x9:5x4.5:-12:-;33x12.50R17:17x9:5x4.5:+0:-;305/70R17:17x9:5x4.5:+0:-;295/70R17:17x9:5x4.5:+0:-;285/75R17:17x9:5x4.5:+0:-;285/70R17:17x9:5x4.5:+0:-;275/70R17:17x9:5x4.5:+0:-;33x12.50R17:17x9:5x4.5:+1:-;305/70R17:17x9:5x4.5:+1:-;295/70R17:17x9:5x4.5:+1:-;285/75R17:17x9:5x4.5:+1:-;285/70R17:17x9:5x4.5:+1:-;275/70R17:17x9:5x4.5:+1:-;33x12.50R18:18x8.5:5x4.5:+0:-;305/60R18:18x8.5:5x4.5:+0:-;295/70R18:18x8.5:5x4.5:+0:-;285/65R18:18x8.5:5x4.5:+0:-;275/75R18:18x8.5:5x4.5:+0:-;275/65R18:18x8.5:5x4.5:+0:-;33x12.50R18:18x8.5:5x4.5:+1:-;305/60R18:18x8.5:5x4.5:+1:-;295/70R18:18x8.5:5x4.5:+1:-;285/65R18:18x8.5:5x4.5:+1:-;275/75R18:18x8.5:5x4.5:+1:-;275/65R18:18x8.5:5x4.5:+1:-;33x12.50R18:18x9:5x4.5:-12:-;33x12.50R18:18x9:5x4.5:+0:-;305/60R18:18x9:5x4.5:+0:-;285/65R18:18x9:5x4.5:+0:-;275/65R18:18x9:5x4.5:+0:-;33x12.50R18:18x9:5x4.5:+1:-;305/60R18:18x9:5x4.5:+1:-;285/65R18:18x9:5x4.5:+1:-;275/65R18:18x9:5x4.5:+1:-;33x12.50R20:20x9:5x4.5:-12:-;305/55R20:20x9:5x4.5:-12:-;285/55R20:20x9:5x4.5:-12:-;33x12.50R20:20x9:5x4.5:+0:-;33x12.50R20:20x9:5x4.5:+1:-;33x12.50R20:20x10:5x4.5:-19:Minor Trimming;305/55R20:20x10:5x4.5:-19:Minor Trimming;285/55R20:20x10:5x4.5:-19:Minor Trimming;33x12.50R20:20x10:5x4.5:-18:Minor Trimming;305/55R20:20x10:5x4.5:-18:Minor Trimming;285/55R20:20x10:5x4.5:-18:Minor Trimming
Tire, Wheel, and Offset Info 33x12.50R15:15x8:5x4.5:-19:-; 33x10.50R15:15x8:5x4.5:-19:-; 33x12.50R15:15x8:5x4.5:-18:-; 33x10.50R15:15x8:5x4.5:-18:-; 33x12.50R15:15x8:5x4.5:-12:-; 33x10.50R15:15x8:5x4.5:-12:-; 33x12.50R15:15x8:5x4.5:-6:-; 33x10.50R15:15x8:5x4.5:-6:-; 33x12.50R15:15x8:5x4.5:+0:-; 33x10.50R15:15x8:5x4.5:+0:-; 33x12.50R15:15x8:5x4.5:+1:-; 33x10.50R15:15x8:5x4.5:+6:-; 33x12.50R16:16x8:5x4.5:-19:-; 285 75R16:16x8:5x4.5:-19:-; 33x12.50R16:16x8:5x4.5:-18:-; 285 75R16:16x8:5x4.5:-18:-; 33x12.50R16:16x8:5x4.5:-12:-; 285 75R16:16x8:5x4.5:-12:-; 33x12.50R16:16x8:5x4.5:-6:-; 285 75R16:16x8:5x4.5:-6:-; 33x12.50R16:16x8:5x4.5:+0:-; 285 75R16:16x8:5x4.5:+0:-; 33x12.50R16:16x8:5x4.5:+1:-; 285 75R16:16x8:5x4.5:+6:-; 285 75R16:17x8:5x4.5:-19:-; 285 70R17:17x8:5x4.5:-12:-; 285 70R17:17x8:5x4.5:+0:-; 285 70R17:17x8:5x4.5:+6:-; 285 70R17:17x8.5:5x4.5:-12:-; 33x12.50R17:17x8.5:5x4.5:+0:-; 285 70R17:17x8.5:5x4.5:+0:-; 33x12.50R17:17x8.5:5x4.5:+1:-; 33x12.50R17:17x9:5x4.5:-12:-; 285 70R17:17x9:5x4.5:-12:-; 33x12.50R17:17x9:5x4.5:+0:-; 33x12.50R17:17x9:5x4.5:+1:-; 285 70R17:17x9:5x4.5:+1:-; 285 65R18:18x8:5x4.5:-19:-; 285 65R18:18x8:5x4.5:-12:-; 285 65R18:18x8:5x4.5:+0:-; 285 65R18:18x8:5x4.5:+6:-; 33x12.50R18:18x8.5:5x4.5:+0:-; 33x12.50R18:18x8.5:5x4.5:+1:-; 33x12.50R18:18x9:5x4.5:-12:-; 33x12.50R18:18x9:5x4.5:+0:-; 33x12.50R18:18x9:5x4.5:+1:-; 285 55R20:20x8:5x4.5:-19:-; 285 55R20:20x8:5x4.5:-12:-; 285 55R20:20x8:5x4.5:+0:-; 285 55R20:20x8:5x4.5:+6:-; 33x12.50R20:20x9:5x4.5:-12:-; 305 55R20:20x9:5x4.5:-12:-; 285 55R20:20x9:5x4.5:-12:-; 33x12.50R20:20x9:5x4.5:+0:-; 33x12.50R20:20x9:5x4.5:+1:-; 33x12.50R20:20x10:5x4.5:-19:-; 305 55R20:20x10:5x4.5:-19:-; 285 55R20:20x10:5x4.5:-19:-; 33x12.50R20:20x10:5x4.5:-18:-; 305 55R20:20x10:5x4.5:-18:-; 285 55R20:20x10:5x4.5:-18:-
