4 Inch Lift Kit - Ram 1500 4WD
Give your RAM 1500 the perfect blend of performance, protection, and style with Rough Country's 4-inch Suspension Lift. Designed to offer an affordable way to maximize off-road performance and run up to 35-inch tires, these kits offer high quality, heavy-duty equipment for new model RAM 1500's. Utilizing heavy-duty, laser cut, steel equipment engineered by Rough Country, these 4-inch Suspension Lifts are complete kits that include everything needed for outstanding off-road performance. High-clearance front and rear cross-members provide enough room for off-road climbs and runs. A heavy-duty skid plate shields the vehicle's differential, protecting you from hazardous terrain. A durable set of driver and passenger side lifted cast knuckles are also included, helping to promote proper geometry once the vehicle is lifted. For true trailblazers, this kit also ships with a set of rear N3 Nitrogen-charged shock absorbers - valved specifically for a blend of on and off-road performance. Includes Rough Country's Lifetime Replacement Guarantee!
- Maintains factory ride quality
- Increased ground clearance
- Levels the front with the rear of the vehicle
Information:
Kit is not recommended for AWD models. "TRX" models will achieve approximately 1" of additional lift. Requires 20" or larger wheels! Does NOT fit 18" or smaller wheels.
Application Summary:
| Year |
Make/Model |
| 2009-2010 |
Dodge Ram 1500 |
| 2011 |
Ram 1500 |
| Attributes |
| California Proposition 65 |
WARNING: Cancer - www.P65Warnings.ca.gov |
| Category |
Susp Lift Kits 4wd |
| Country of Origin (Primary) |
US |
| Front Components |
Lifted knuckles Strut spacers Front crossmember Rear crossmember Differential drop brackets Driveshaft spacer Sway-bar links Skid plate Hardware, Lifted knuckles Strut spacers Front crossmember Rear crossmember Differential drop brackets Driveshaft spacer Sway-bar links Skid plate Hardware |
| Front Kit Componenets |
Lifted knuckles, Strut spacers, Front crossmember, Rear crossmember, Differential drop brackets, Driveshaft spacer, Sway-bar links, Skid plate, Hardware |
| Front Kit Components |
Lifted knuckles, Strut spacers, Front crossmember, Rear crossmember, Differential drop brackets, Driveshaft spacer, Sway-bar links, Skid plate, Hardware |
| GTIN |
00843030148959 |
| Harmonized Tariff Code (Schedule B) |
8708809900 |
| Hazardous Material Code |
N |
| Install Time |
4 - 6 hours, 4 - 6 hours |
| Life Cycle Status Code |
Available to Order |
| Lift/Drop Height |
4 in. |
| NAFTA Preference Criterion Code |
B |
| Rear Components |
Upper coil spacers Sway-bar links Bump-stop brackets Brake line brackets Hardware, Upper coil spacers Sway-bar links Bump-stop brackets Brake line brackets Hardware |
| Rear Kit Components |
Upper Coil Spacers, Sway-bar links, Bump-stop brackets, Brake line brackets, Hardware |
| SDR Required Flag |
N |
| Shipping Options |
No Restrictions |
| Ships in Multiple Boxes |
Y |
| Tire Info |
35x12.50R20:20x9:5x5.5:+0:Minor Trimming;295/60R20:20x9:5x5.5:+0:Minor Trimming;35x12.50R20:20x9:5x5.5:+1:Minor Trimming;295/60R20:20x9:5x5.5:+1:Minor Trimming |
| Tire, Wheel, and Offset Info |
35x12.50R20:20x9:5x5.5:+12:-; 35x12.50R22:22x10:5x5.5:-12:Minor Trimming |
