Suspension Lift Kit; 7.5 in.; Lifted Knuckles; Strut Spacers; Front/Rear Crossmember; Sway-Bar; Drop Brackets; Brake Line Brackets;
This all-inclusive kit ships with everything you need to get going and hit the mudholes. Featuring a set of beefy lifted knuckles and 1/4in thick steel front and rear high-clearance crossmembers, this kit offers plenty of muscle to handle hazards both on and off-road. A set of Lifted Coil Springs and Upper Strut Spacers provide plenty of ride height - enough to run up to a 33in tire on our 5in option, or a 35in tire on our 7.5in option. Both kits feature sway-bar links, shock extensions, brake line brackets, a rough and tumble lower skid plate, and Grade 8 Hardware. Included sway-bar drop brackets and differential drop brackets help keep vehicle components properly aligned after lifting, providing a factory-like ride while boasting an aggressive stance.
- Unmatched ground clearance from
- High clearance crossmember design
- 100% precision laser cut materials used in latest computer aided design process
- No strut disassembly or strut compressor required for installation
- Requires no modification to the stock differential mounts, drivetrain or exhaust
- Provides highly sought level stance when complete.
Information:
Does NOT fit Auto Ride or Auto Leveling models. Does NOT fit models with electric steering. AWD models will require driveline modifications (Must be converted to not be AWD). Minor cutting and drilling is required. 18in or larger wheels are required. Please view instructions for complete information on proper tire/wheel combinations.
Application Summary:
| Year |
Make/Model |
| 2007-2014 |
Chevrolet Tahoe |
| 2007-2014 |
GMC Yukon |
| Attributes |
| California Proposition 65 |
WARNING: Cancer - www.P65Warnings.ca.gov |
| Category |
Susp Lift Kits 4wd |
| Country of Origin (Primary) |
US |
| Front Components |
Lifted knuckles, Front crossmember, Rear crossmember, Upper strut spacers, Differential drop brackets, CV spacers, Sway-bar brackets, Lower skid plate, Brake line brackets, Hardware |
| Front Kit Components |
Lifted knuckles, Front crossmember, Rear crossmember, Upper strut spacers, Differential drop brackets, CV spacers, Sway-bar brackets, Lower skid plate, Brake line brackets, Hardware |
| GTIN |
00843030127831 |
| Harmonized Tariff Code (Schedule B) |
8708809900 |
| Hazardous Material Code |
N |
| Install Time |
8-10 hours |
| Life Cycle Status Code |
Available to Order |
| Lift/Drop Height |
7.5 in. |
| NAFTA Preference Criterion Code |
B |
| Rear Components |
Lifted coil springs, Coil spring spacers, Sway-bar links, Track bar bracket, Shock extensions, Hardware |
| Rear Kit Components |
Lifted coil springs, Coil spring spacers, Sway-bar links, Track bar bracket, Shock extensions, Hardware |
| SDR Required Flag |
N |
| Shipping Options |
No Restrictions |
| Ships in Multiple Boxes |
Y |
| Tire & Wheel Size Combinations |
295/60R20 on Factory 20 - 6x5.5 with .25in Spacer, 295/70R18 on Factory 18 - 6x5.5 with .25in Spacer, 315/55R20 on 20x9 - 6x5.5, +12 offset, 315/55R20 on 20x9 - 6x5.5, +18 offset, 315/65R18 on 18x9 - 6x5.5, +12 offset, 315/65R18 on 18x9 - 6x5.5, +18 offset |
| Tire, Wheel, and Offset Info |
295 70R18:Factory 18:6x5.5:-:0.25 Spacer; 295 60R20:Factory 20:6x5.5:-:0.25 Spacer; 285 70R18:18x9:6x5.5:+12:-; 285 70R18:18x9:6x5.5:+18:-; 35x11.50R20:20x9:6x5.5:+12:-; 35x11.50R20:20x9:6x5.5:+18:-; 295 60R20:20x9:6x5.5:+18:-; 295 60R20:20x9:6x5.5:+20:- |
