ORACLE Lighting 5" 24W Angled LED Scene Light
This new auxiliary light design from ORACLE Lighting incorporates both TIR (Total Internal Reflection) and LED Reflector Facing Technology to create a high-quality light output with a precision beam pattern. By combining both optic technologies this light provides an average 30 degree beam pattern and projects up to nearly 500M overall distance. The integrated LED marker lights feature both White and Amber LEDs which can be utilized for parking lights, DRL, and/or Turn Signals.
This new auxiliary light design from ORACLE Lighting incorporates both TIR (Total Internal Reflection) and LED Reflector Facing Technology to create a high-quality light output with a precision beam pattern. By combining both optic technologies this light provides an average 30 degree beam pattern and projects up to nearly 500M overall distance. The integrated LED marker lights feature both White and Amber LEDs which can be utilized for parking lights, DRL, and/or Turn Signals.
- Flood Beam(70 Degree)
- Multi-Surface TIR LENS
- Anti Rust/Corrosion/Freezing Resistance
- Electronic Thermal Management (ETM)
- Surface Mount(35 Degree & 48 Degree)
- ECE R23/R10,CE,CISPR25
- Over/Under Voltage Protection
- Reverse Polarity Protection
- UV Resistant, Shock Resistant
- IP68/69K Waterproof Breather
- 50,000+ Hr LED Lifespan
- 1 Year Warranty
Information:
5,700K| Attributes | |
| AMP Draw | (12V/24V): 1.6A / 0.8A |
| Add-On | N/A |
| California Proposition 65 | WARNING: Cancer - www.P65Warnings.ca.gov |
| Country of Origin (Primary) | US |
| Dimensions | 130 x 42 x 42 mm |
| Effective Lumens | 2200 |
| Finish | Anodized Polyester Powdercoat |
| GTIN | 00810030397052 |
| Harmonized Tariff Code (Schedule B) | 8512200000 |
| Hazardous Material Code | N |
| Kelvin Temperature | 5700K |
| LED | (4x) 6W LED |
| Life Cycle Status Code | Available to Order |
| NAFTA Preference Criterion Code | B |
| Peak Beam Intensity(cd) | 3400 |
| Raw Lumens | 2800 |
| SDR Required Flag | N |
| Voltage | DC9-36V |
| Warranty Time | 1 |
Oracle Lighting 2916-001 5" 24W Angled LED Scene Light
Product Information
- Brand: Oracle Lighting
- Product Number: 2916-001
