CURT 16545 Q24 5th Wheel Hitch Head Only; Legs or Roller Required; 24;000 lbs

---

The CURT Q24 is the heavyweight champion of 5th wheel hitches. With a gross trailer weight capacity of 24,000 lbs. and a vertical load limit of 6,000 lbs., the Q24 is capable of handling the heaviest of 5th wheel trailers, including deluxe RV and oversize campers. Something that sets the Q24 5th wheel hitch apart from competitive models is its spherical axial bearing. Instead of having a set of rods on which the hitch head can pivot, the Q24 uses a spherical bearing to allow the hitch head to pivot in virtually any direction. This means smoother turns, a quieter ride and less strain on your towing equipment and truck. The CURT Q24 5th wheel trailer hitch also features dual-locking jaws, a self-aligning head, single-handle operation and a three-position coupling indicator. It comes with a durable carbide powder coat finish, a limited lifetime warranty and is tested in accordance with SAE J2638 for safety. This 24K 5th wheel hitch head comes ready to be attached to the CURT R24 5th wheel roller or 5th wheel legs (includes head only). Certain turret-style pin boxes, such as Sidewinder, are not compatible with CURT Q-series hitches and should not be used as they may create vehicle / trailer handling hazards. Please contact CURT Product Support for compatibility information.

• Mounts On The R24 Roller PN[16570] And Tow Up To 24000 Lbs.
• Incl. A Polyethylene Lube Plate To Eliminate Messy Grease Deposit
• Protected By A Highly Durable Carbide Powder Coat Finish
• Backed By A 10-Year Limited Warranty
• Spherical Axial Bearing For Unimpeded Movement And Quiet Towing
• Dual Jaws Provide 360-Degree Kingpin Contact
• Three-Position Coupling Indicator Is Visible From Truck Cab
• Self-Aligning Head Offers A Wide Opening For Easy Coupling
• Operates Using A Short Lockable Single-Throw Handle
• Three Grease Fittings For Easy Lubrication

---

Information:

Includes a polyethylene lube plate to eliminate messy grease deposits; Tested for safety in accordance with SAE J2638; Protected by a highly durable carbide powder coat finish; Limited lifetime warranty (one-year finish, one-year parts); Q24 5th Wheel Hitch Head; Requires CURT 5th wheel roller or legs for installation; Spherical axial bearing tilts head in any direction for a smooth, quiet ride; Dual jaws fully wrap the kingpin to reduce chucking and increase security; Wide, self-aligning head helps eliminate errors when backing up to the trailer; Lockable, short-throw handle automatically engages with the kingpin; Three easy-access grease fittings for lubrication; Three-position coupling indicator clearly shows coupling status; Offers three height adjustment positions to adapt to each unique truck bed

---

Application Summary:

Year	Make/Model
CURT	16545 Q24 5th Wheel Hitch Head Only, Legs or Roller Required, 24,000 lbs
