CURT 15845 Commercial Duty Class 5 Trailer Hitch; 2-1/2-Inch Receiver; Compatible with Select Ford F-350; F-450; F-550 Super Duty; F-650

---

In the world of commercial towing, more is expected. A job cannot be completed if the equipment cannot handle the workload. That is why CURT developed the Commercial Duty class 5 trailer hitch. Constructed from steel and engineered for power, these class 5 hitches are designed to complement the towing power of full-size, commercial pickup trucks, including diesels and chassis cabs. They can easily handle a variety of oversize trailers, including toy and car haulers, livestock trailers, dumper trailers, large flatbed trailers, large boat trailers and more (NOTE: Never exceed the lowest weight capacity of any towing component). This particular class 5 hitch features a gross trailer weight capacity of 20,000 lbs. and a tongue weight capacity of 2,700 lbs. It is designed to be a custom trailer hitch for certain years of the Ford F350 Super Duty, F450 Super Duty, F550 Super Duty and F650 (to verify your vehicle compatibility, see application info). All CURT Commercial Duty class 5 hitches feature a 2-1/2 in. x 2-1/2 in. receiver tube opening to accept the strongest of ball mounts and towing accessories. They are perfect for mounting standard ball mounts, pintle mounts, tow hooks and weight distribution hitches as well as winch mounts and cargo carriers. CURT class 5 tow hitches are protected by a co-curing of liquid A-coat and carbide black powder coat finish. They also mount with grade-8 hardware, included with each hitch.

• Made w/A Vehicle-Specific Design For A Custom Fit
• Features Wide Safety Chain Openings For Heavy-Duty Hooks
• Backed By A Limited Lifetime Warranty
• Made in USA [may include imported hardware]
• Tested For Safety In Accordance w/SAE J684
• Precisely Welded For Superior Strength And Fit
• Constructed w/A Large Powerful Main Body
• Protected By A Highly Durable Carbide Powder Coat Finish
• Co-Cured In A Rust-Resistant Liquid Bonderite Coating
• Strengthened w/A Cast Welded Seamless Collar

---

Information:

Rated to 20,000 lbs. gross trailer weight and 2,700 lbs. tongue weight; Compatible with weight distribution hitch (20,000 lbs. WD / 2,700 lbs. WDTW); Engineered with a vehicle-specific design for a custom fit; Tested for safety in accordance with SAE J684; Precisely welded for superior strength and fit; Constructed with a large, powerful main body; Protected by a highly durable carbide powder coat finish; Co-cured in a rust-resistant liquid A-coat, inside and out; Features wide safety chain openings for heavy-duty hooks; Equipped with an open-back receiver for easy cleaning; Limited lifetime warranty (one-year finish, one-year parts); Made in USA (may include imported hardware); Commercial Duty Class 5 Hitch, 2-1/2, Select Ford F350, F450, F550, F650

---

Application Summary:

Year	Make/Model
1999-2007	Ford F-450 Super Duty
2019-2025	Ford F-450 Super Duty
1999-2018	Ford F-550 Super Duty
2020-2025	Ford F-550 Super Duty
2000-2013	Ford F-650
2015-2019	Ford F-650
2021-2025	Ford F-650
2012-2013	Ford F-750
